Product Description

2500HBFP 1350 Litre Tuffa Bunded Fire Protected Tank

2500 litre (approx. 550 gallons) bunded Fire Protected storage tank.

This quality fire protected tank is suitable for domestic fuel oil storage. The tank consists of an inner and outer tank, with a fire protection layer which provides either 30 or 60 minutes of protection.Tuffa fire protected oil tanks come with internal fire protection (not an externally constructed fire wall) which offers quick, easy, affordable & convenient installation.

Tuffa’s fire protected oil tanks serve as an alternative means of compliance when compared to traditional fire barriers. Tuffa’s fire protected tank system has LABC certification proving compliance with local authorities across Britain. However, it is the responsibility of the Competent Person installing the tank, or the building inspector certifying the installation, to ensure a site-specific risk assessment has been conducted.


Supplied complete with:

  • Fire Protection
  • 2" BSP Fill Connection with cap and chain
  • Overfill prevention valve
  • Vent
  • Manual Float Level Gauge
  • Lockable Flip Lid
  • 1" Bottom Outlet
  • Electronic Watchman Sonic Gauge
  • Tank Fittings Kit (1" - 1/2" adaptor, ball valve and filter)

Benefits -

  • Local Authority Building Control (LABC) Assurance certified proving compliant with Building Regulations in Britain
  • Indepently tested to BS476: Part 22: 1987
  • Independently tested to BS476 (Warrington Fire Research Centre)
  • Meets Section J 5.4 of Building Regulations, Table 5.1 for Fire Protection for Oil Storage Tanks

30 minute fire protection

Enables the installation of an oil tank a minimum of 300mm from other buildings and structures. Where access is required (e.g. at the front of the tank to fill it) then a minimum distance of 600mm is required.

60 minute fire protection

Enables the installation of an oil tank within a garage or other internal space where it is impractical to install the tank externally to the building. The tank must be installed in an uninhabitable area (e.g. a garage or outbuilding), at the lowest possible level in the building or structure. Additionally, the tank must be installed a minimum of 300mm from other internal walls and structures or 600mm where access is required.

Top Outlet tanks are a "Special Order" and therefore "Non-Returnable".

Manufactured from recyclable polyethylene, this UK made Tuffa tank is corrosion resistant, has high impact strength and is UV stabilised.

Please check current building regulations for up to date rules on oil storage and fire protection requirements.

Product Code: 2500HBFP

Lead Time: approx. 3 weeks

from £1990.00 ex VAT
(£2,388.00 inc VAT)
Choose Outlet:
Choose Fire Protection:
Delivery Options
  • Free Delivery to Mainland UK - Customer offloading (Postcode exclusions apply to AB, BT, DD, EH, FK, G, GY, HS, IM, IV, JE, KA, KW, KY, ML, PA20+ & PH, PO30+, ZE)

Certain postcodes in Wales, Scotland, highlands and Islands may have additional charges, please click here to check your postcode

up down
Tail Lift Delivery Diesel, Gas Oil, Heating Oil Diesel, Gas Oil, Heating Oil Diesel, Gas Oil, Heating Oil

Delivery Options: Tail Lift Delivery

Fire Protection: 30 Minutes, 60 Minutes

Guarantee: 10 Year Guarantee

Made From: Plastic

Suitable For Fuel: Diesel, Gas Oil, Heating Oil

Tank Shape: Vertical

Tank Type: Bunded

Capacity: 2440 litres

Weight: 310.00kg

Dimensions (l x w x h): 2840mm x 1520mm x 1630mm

Supplied with a Watchman Sonic gauge and Tank fitting kit

Write the first review

pdf2500HBFP Technical Specifications

pdfTuffa Tank Inspection Maintenance Guidelines

pdfTuffa FP30 FireStop Domestic Certificate

pdfTuffa FP60 FireStop Domestic Certificate

pdfTuffa FP60 FireStop Non-Domestic Certificate

Item: TF

What is a bunded tank?

A bunded tank consists of a 'tank within a tank'.

The inner tank is the primary storage vessel, whilst the outer tank acts as a failsafe.

In the event of a spill, surplus fuel will safely and securely be stored within the outer tank and an environmental pollution incident will be averted.

Installation requirements

All TUFFA Fire Protected tanks should be installed on a level non-combustible base which extends 300mm beyond the perimeter of the tank (with the exception of any sides which are adjacent fire rated walls - in this case, a minimum of 100mm should be provided). The installation should be completed by a competent person and signed off either through building control or a competent persons scheme (such as APHC).

Fuel Tank Shop and the manufacturer will not be responsible for oil tank installations which do not comply with these requirements.

OFTEC Base Construction Guidelines (in brief):

  • Adequate for the weight of the tank when full
  • Non-combustible, imperforate and level
  • Constructed of concrete, paving stones or stonework
  • Large enough to extend 300mm beyond ALL sides of the tanks
