5000 Litre Bunded Fuel Point - Harlequin 5000FP AGRI

Product Ref: 5000FP AGRI

Comes supplied with 240v pump, overfill prevention, 6 m hose and auto nozzle

Customer Offloading 10 Year Guarantee - Tank only Plastic Diesel, Gas Oil, HVO Diesel, Gas Oil, HVO Diesel, Gas Oil, HVO Vertical Bunded
  • Volume: 5314ltr
  • Weight: 350.000kg
  • Dimensions: H:2210mm
  • Diameter: 2360mm
  • Lead time approx. 5 - 10 working days

    Home Delivery

    United Kingdom mainland delivery from FREE ex VAT

    FREE STANDARD Delivery for HARLEQUIN Tanks - Via articulated lorry, customer to off-load (Postcode exclusions apply to Highlands & Islands)

    check delivery cost

    Choose Mechanical Flow Meter:
    Choose Filter:

    updown
    from £2,949.00 ex VAT
    (£3,538.80 inc VAT)
    You may also need:
    Boot Cleaner Premium
    Boot Cleaner Premium
    £467.00 ex VAT
    (£560.40 inc VAT)
    65 Litre Fuel Spill Kit - Round Drum OSK6
    65 Litre Fuel Spill Kit - Round Drum OSK6
    £89.00 ex VAT
    (£106.80 inc VAT)

    5000 Litre Bunded Fuel Point - Harlequin 5000FP AGRI What is a bunded tank?

    A bunded tank consists of a 'tank within a tank'.

    The inner tank is the primary storage vessel, whilst the outer tank acts as a failsafe.

    In the event of a spill, surplus fuel will safely and securely be stored within the outer tank and an environmental pollution incident will be averted.

    5000 Litre Bunded Fuel Point - Harlequin 5000FP AGRI Downloadable Documents

    5000 Litre Bunded Fuel Point - Harlequin 5000FP AGRI Description

    5000FP AGRI Bunded Fuel Point

    5000 litre (1000 gallons) bunded diesel tank. Supplied with 240V pump, 6 m hose and auto nozzle.

    The Harlequin Fuel Point is ideal for smaller, commercial, industrial and agricultural storage installations where the added value technologies incorporated into the Fuel Station range, are not required.


    Supplied complete with:

    • 230v Electric Pump with 56lpm Nominal Flow Rate
    • Offset 2” BSP Lockable Fill Point with Screw Cap, Lever Type Isolation Valve and Non-Return Valve
    • 4” Lockable Inspection Point with Plastic Screw Cap
    • LRC Failsafe Overfill Prevention Capability
    • Integral Bunding
    • Tank Vent
    • Cement base length 2810 mm x cement base width 2960 mm
    • Lockable Cabinet Access
    • 6 m Delivery Hose (1") with Automatic Shut Off Dispensing Nozzle

    Optional Extras

    • 10 micron Particulate Filter
    • Factory fitted Mechanical Flow Meter with Resettable Batch Totaliser
    • HVO Kit

    5000 Litre Bunded Fuel Point - Harlequin 5000FP AGRI Specification

    • Product Code: HQ
    • Delivery Options: Customer Offloading
    • Guarantee: 10 Year Guarantee - Tank only
    • Made From: Plastic
    • Suitable For Fuel: Diesel, Gas Oil, HVO
    • Tank Shape: Vertical
    • Tank Type: Bunded

    5000 Litre Bunded Fuel Point - Harlequin 5000FP AGRI Delivery Information

    Prices quoted include delivery to mainland UK and Northern Ireland locations, but excludes offshore islands and locations.

    Delivery is a kerbside delivery service only and not a "drop at your door service".

    Arrangements must be made by the customer to manoeuvre tanks into position.

    On tanks with a capacity of 2,500 litres deliveries can be made by articulated lorry, and it is the customers' responsibility to ensure safe and adequate access for large lorries plus off loading facilities at the delivery address.

    Off loading of heavy items should be made by fork lift or similar heavy lifting equipment

    Tanks cannot be left without a customer signature

    5000 Litre Bunded Fuel Point - Harlequin 5000FP AGRI Returns Information

    Customers may return items within 14 calendar days (as per our Terms & Conditions) - refer to section 7. **

    All Items must be returned unused, refunds cannot be issued for used or previously installed items.

    Please be aware that returning a tank can be complicated and expensive, so please check that you are ordering the correct item (we suggest checking the dimensions very carefully).

    If you wish to return goods, please complete the form on this page to provide further information.

    Once your request is approved, a valid Returns Authorisation Number (RAN) will be issued to initiate the returns process along with information on how & where to return your order along with any costs involved.

    Please DO NOT return any goods without this authorisation. Goods cannot be accepted without this.

    Returns are not accepted at our Minehead Office, please wait until we contact you before returning any goods.

    View Fuel Tank Shop return policy now.
